Rockwell Automation 1738-OE4CM12 ArmorPoint 4-Channel 24V dc Analog Output Modules, Series A User Manual
Page 15
ArmorPoint 4-Channel 24V dc Analog Output Modules, Series A 15
Publication
1738-IN025C-EN-P - March 2010
EFT/B immunity
IEC 61000-4-4:
±3 kV at 5 kHz on signal ports
Surge transient
immunity
IEC 61000-4-5:
±1 kV line-line (DM) on signal ports
±2 kV line-earth (CM) on signal ports
Conducted RF immunity
IEC 61000-4-6:
10V rms with 1 kHz sine-wave 80%AM from 150 kHz…80 MHz
Certifications
Certification (when
product is marked)
(1)
Value
CE
European Union 2004/108/EC EMC Directive, compliant with:
EN 61326; Meas./Control/Lab., Industrial Requirements
EN 61000-6-2; Industrial Immunity
EN 61000-6-4; Industrial Emissions
EN 61131-2; Programmable Controllers (Clause 8, Zone A & B)
C-Tick
Australian Radiocommunications Act, compliant with:
AS/NZS CISPR11; Industrial Emissions
(1)
See the Product Certification link at for Declarations of Conformity, Certificates,
and other certification details.
Environmental (Continued)
Attribute Value
