ArmorPOINT I/O DeviceNet Adapters 13
Publication
1738-IN014D-EN-E - December 2010
Specifications
Attributes
Value
Expansion I/O capacity
63 modules max.
Actual number of modules can vary.
Add up current requirements of modules you want to use to make sure they
do not exceed the amperage limit of 1.0 A for the ArmorPOINT I/O
DeviceNet adapter.
Backplane current can be extended beyond 1.0 A with a 1738-EP24DC
Backplane Extension Power Supply. The 1738-EP24DC can supply up to an
additional 1.3 A of backplane current.
Add multiple 1738-EP24DC modules to reach the 63 module max.
POINTBus current
requirements
75 mA – 1738-IB2M12, 1738-IB4xxx, 1738-IB8xxx,1738-IV4xxx,
1738-OB2EM12, 1738-OB2EPM12, 1738-OB4Exxx,
1738-OB8Exxx, 1738-OV4EM12, 1738-IE2CM12,
1738-OE2CM12, 1738-IE2VM12, 1738-OE2VM12, 1738-IA2xxx,
1738-OA2xxx, 1738-IT2IM12, 1738-232ASCM12, 1738-485ASCM12
90 mA – 1738-OW4xxx
110 mA – 1738-SSIM23
160 mA – 1738-IJM23
180 mA – 1738-VHSC24M23
220 mA – 1738-IR2M12
DeviceNet
communication
Baud rates
Distance, max
125, 250, 500 Kbps
500 m (1630 ft) @ 125 Kbps
250 m (820 ft) @ 250 Kbps
100 m (328 ft)@ 500 Kbps
DeviceNet cable
Allen-Bradley part number 1485C-P1-Cxxx
Refer to publication
Input voltage rating, nom
24V DC
DeviceNet input
voltage range
11…25V DC DeviceNet specification
Input overvoltage
protection
Reverse polarity protected
DeviceNet power
requirements
24V DC (+4% = 25V DC) @ 50 mA max
