ArmorPOINT I/O DeviceNet Adapters 11
Publication
1738-IN014D-EN-E - December 2010
DeviceNet status
Off
Device is not online:
- Device attempting to AutoBaud
- Device has not completed dup_MAC-ID test
- Device not powered – check adapter status indicator.
Flashing green
Device is online but has no connections in the established state.
Green
The device is online and has connections in the
established state.
Flashing red
One or more connections have timed out.
Red
Critical link failure – failed communication device. Device
detected error that prevents it from communicating on the
network. Possible duplicate MAC ID or baud rate mismatch.
POINTBus status
Off
Device is not online:
- Device has not completed dup_MAC-ID test
- Device not powered – check adapter status indicator.
Green
Device is online and has connections in the established state.
Flashing green
Device is online but has no connections in the established state.
Red
Critical link failure – failed communication device. Device
detected error that prevents it from communicating on the
network. Possible duplicate MAC ID or baud rate mismatch.
Flashing red
One or more I/O connections in timed out state.
Flashing
red/green
Communication faulted device – the device has detected a
network access error and is in communication faulted state.
Device has received and accepted an Identify Communication
Faulted Request – long protocol message.
POINTBus status
(1738-ADNX only)
Off
No power applied to device.
Device not online
Device has not completed dup_MAC_ID test.
Green
Subnet online and has connections in the established state.
Red
Unrecoverable fault may require device replacement. There is
possible duplicate MAC ID or baud rate mismatch.
Flashing red
Recoverable fault:
- No scanlist configured
- Problem with module in scanlist (missing, mismatch).
Indicator Status
Indicator
Status
Description
