Specifications
Characteristic Value
Power Requirements
5V dc @ 465mA (1)
Power Consumption
Thermal Dissipation
5 V dc, 2.33W
8.0 BTU/hr
Isolation Voltage Tested to withstand 500V ac for 60 seconds
Ethernet Conductors
Wiring
Category
802.3 compliant - twisted pair
2
(2)
Ethernet Connector RJ45 Category 5
Emissions CISPR 11: Group 1, Class A (with appropriate enclosure)
ESD Immunity IEC 61000-4-2:
6kV contact discharges
8kV air discharges
Radiated RF Immunity IEC 61000-4-3:
10V/m with 1kHz sine-wave 80%AM from 30MHz to 2000MHz
10V/m with 200Hz 50% Pulse 100%AM at 900Mhz
EFT/B Immunity IEC 61000-4-4:
±2kV at 5kHz on communications ports
Surge Transient Immunity IEC 61000-4-5:
±2kV line-earth (CM) on communications ports
Conducted RF Immunity IEC 61000-4-6:
10Vrms with 1kHz sine-wave 80%AM from 150kHz to 80MHz
Enclosure Type Rating None (open-style)
Operating Temperature IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock):
This product is suitable for application in equipment that is rated 0 to 60
o C
(32 to 140 o F) maximum. It is acceptable for the ambient slot temperature
immediately surrounding this product to reach 85 o C (185 o F) maximum.
Storage Temperature IEC 60068-2-1 (Test Ab, Un-packaged Non-operating Cold),
IEC 60068-2-2 (Test Bb, Un-packaged Non-operating Dry Heat),
IEC 60068-2-14 (Test Na, Un-packaged Non-operating Thermal Shock):
–40 to 85°C (–40 to 185°F)
Relative Humidity IEC 60068-2-30 (Test Db, Un-packaged Non-operating Damp Heat):
5 to 95% non-condensing
Shock IEC60068-2-27 (Test Ea, Unpackaged Shock):
Operating 30g
Non-operating 50g
