MicroLogix 1762-OB32T Solid State 24V DC Source Output Module 17
Publication 1762-IN020B-EN-P - June 2013
Specifications
General Specifications
Attribute Value
Number of outputs 32
Dimensions
HxWxD 90 x 40.4 x 87 mm
(3.54 x 1.59 x 3.43 in.)
Shipping weight, approx. 200 g (7.05 oz)
Bus current draw, max 175 mA @ 5V DC
0 mA @ 24V DC
Heat dissipation 3.4W @ 26.4V DC
Wire size 22, 24, 26 AWG solid or stranded copper wire rated at 90 °C (194 °F)
Wiring category (1)
(1) Use this Conductor Category information for planning conductor routing. Refer to Industrial Automation Wiring and
Grounding Guidelines, publication
1770-4.1 .
2 - on signal ports
Pilot duty rating Not rated
Enclosure type rating IP20
North American temp code T3C
Output Specifications
Attribute Value
Isolated groups Group 1: Outputs 0...15
Group 2: Outputs 16...31 (internally connected to common)
Output group to backplane
isolation Verified by one of the following dielectric tests:
1200V AC for 2 s or 1697V DC for 2 s.
75V DC working voltage (IEC Class 2 reinforced insulation)
Vendor I.D. code 1
Prduct type code 7
Product code 100
Voltage category 24V DC source
Operating voltage range 10.2...26.4V DC
Signal delay, max
resistive load Turn-on = 0.5 ms
Turn-off = 4.0 ms
Off-state leakage, max 0.1 mA @ 26.4V DC
On-state voltage drop 0.3V DC @ 0.5 A
