ProcessLogix Fieldbus Interface Module (FIM) 9
Publication 1757-IN913A-EN-P - October 2001
Enclosure Type Rating
None (open-style)
Barometric Pressure
Altitude
-300 to +3000 m
Certifications:
(when product is marked)
UL
UL Listed Industrial Control
Equipment
CSA
CSA Certified Process Control
Equipment for Class I, Division 2
Group A,B,C,D Hazardous
Locations
FM
FM Approved Equipment for use in
Class I Division 2 Group A,B,C,D
Hazardous Locations
CE
4
European Union 89/336/EEC EMC
Directive, compliant with:
EN 50081-2; Industrial Emissions
EN 50082-2; Industrial Immunity
EN 61326; Meas./Control/Lab.,
Industrial Requirements
EN 61000-6-2; Industrial Immunity
C-Tick
Australian Radiocommunications
Act, compliant with:
AS/NZS 2064; Industrial Emissions
1
Qualified for use with 50 ms CEE only
2
The maximum number of supportable devices per network is highly dependent on application, bandwidth, devices, available
current, bus length and topology. An understanding of Fieldbus is crucial to system sizing.
3
Each FIM network uses 2 VCRs, each device uses 2 VCRs, and each “published” connection to/from a PLX52 FB uses 1 VCR.
Connections between devices do not use FIM VCRs.
4
See the Product Certification link at www.ab.com for Declarations of Conformity, Certificates, and other certification details.
FIM Specifications
