4 ProcessLogix Fieldbus Interface Module (FIM)
Publication 1757-IN913A-EN-P - October 2001
Planning Considerations
Fieldbus Network References
Refer to the following publications for guidance in designing and implementing the
Fieldbus network to be interfaced to the ProcessLogix system through the FIM and
its companion Remote Termination Panel (RTP).
Fieldbus Wiring Selection and Calculation
The recommended cable for connecting Fieldbus devices is #18 AWG (0.8 mm
2
)
shielded, twisted pair wire. It is important to calculate how the planned topology
for your Fieldbus segment, selected wiring, supplied power and intended mix of
Fieldbus devices may impact the overall performance of a Fieldbus network.
Visit the Relcom Inc. website
www.relcominc.com
for more information on
available Fieldbus wiring products and more wiring design and installation data.
They also offer a free Fieldbus Wiring Design and Installation Guide for
downloading.
See the Foundation Fieldbus User Manual, publication 1757-UM006, for a
condensed overview of Fieldbus wiring considerations.
Pub
Number
Publication Title
Scope
Source
AG-140
Wiring and Installation 31.25
kbit/s, Voltage Mode, Wire
Medium Application Guide
Overview of what you need to know
to wire, power, and layout network
components
Fieldbus Foundation
9390 Research Blvd.
Suite II-250
Austin Texas 78759-9780
www.fieldbus.org
AG-163
31.25 kbit/s Intrinsically Safe
Systems
Complements the previous
document, introduces you to the
principles of intrinsic safety, and
outlines how to apply approved
devices in a hazardous area.
AG-165
Fieldbus Installation and
Planning Guide
Outlines things to consider before
installing a Fieldbus network
