Back cover, Mounting dimensions – Rockwell Automation 1794-TB62DS, 1794-TB37DS, 1794-TB62EXD4X15, 1794-TB37EXD4CM8, 1794-TB37EXD4VM8 FLEX I/O D-Shell Terminal Base Units User Manual
Page 6

Publication 1794-IN107A-EN-P - March 2005
6
PN 957928-89
Copyright © 200
7 Rockwell Automation, Inc. All rights reserved. Printed in Singapore.
1.4
(35)
2.3
(59)
1.4
(35)
3.7
(94)
3.4
(87)
3.7
(94)
3.7
(94)
3.7
(94)
3.2
(80)
1.2
(28)
2.0
(50)
0.9
(23)
2.7
(68)
3.2
(80)
0.83 (21)
3.4H x 2.7W x 2.7D
(87H x 68W x 69D)
3.7H x 3.7W x 2.7D
(94H x 94W x 69D)
3.7H x 3.7W x 2.7D
(94H x 94W x 69D)
Secure DIN rail approximately every 200mm.
A = Mounting hole dimensions for optional mounting kit
B = DIN rail
C = Operating temperature 1.0 (25.4) below each module when mounted in any position
must not exceed 55 degrees C (131 degrees F)
Here for vertical
mounting position
with adapter up
Measure here for horizontal position
A
B
C
Terminal Base (1794-TB32S shown)
Terminal Base (1794-TB37DS shown)
Adapter (1794-ASB shown)
Mounting Dimensions
(Millimeters)
Inches
