All Terminal base units are rated at 10A
.
Tighten screws to 5 pound-inches (0.6Nm).
Specifications
Terminal Screw Torque
5 pound-inches (0.6Nm)
Dimensions (with expansion
module installed)
5.0H x 3.7W x 2.7D inches
127.0H x 94W x 69D mm
Current Capacity
1794-TB62DS and 1794-TB62EXD4X15
V2 - 8A maximum
V1 - 6A maximum;
5A per pin
10A maximum per module
1794-TB37DS
10A maximum per module
5A per pin
Voltage Rating
(continuous-voltage
withstand rating)
See chart
Isolation Voltage
Established by installed module
Environmental Conditions
Operating Temperature
IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock):
0 to 55°C (32 to 131°F)
Storage Temperature
IEC 60068-2-1 (Test Ab, Unpackaged Nonoperating Cold),
IEC 60068-2-2 (Test Bb, Unpackaged Nonoperating Dry Heat),
IEC 60068-2-14 (Test Na, Unpackaged Nonoperating Thermal
Shock):
–40 to 85°C (–40 to 185°F)
Relative Humidity
IEC 60068-2-30 (Test Db, Unpackaged Nonoperating
Damp Heat):
5 to 95% noncondensing
Vibration
IEC60068-2-6 (Test Fc, Operating):
5g @ 10-500Hz
Shock
IEC60068-2-27 (Test Ea, Unpackaged shock):
Operating 30g
Non-operating 50g
Emissions
CISPR 11:
Group 1, Class A (with appropriate enclosure)
ESD Immunity
IEC 61000-4-2:
8kV air discharges
Radiated RF Immunity
IEC 61000-4-3:
10V/m with 1kHz sine-wave 80%AM from 30MHz to 2000MHz
10V/m with 200Hz 50% Pulse 100%AM at 900Mhz
10V/m with 200Hz 50% Pulse 100%AM at 1890Mhz
EFT/B Immunity
IEC 61000-4-4:
±2kV at 5kHz on power ports
±2kV at 5kHz on signal ports
Surge Transient
Immunity
IEC 61000-4-5:
±1kV line-line(DM) and ±2kV line-earth(CM) on power ports
±1kV line-line(DM) and ±2kV line-earth(CM) on signal ports
Conducted RF Immunity
IEC 61000-4-6:
10Vrms with 1kHz sine-wave 80%AM from 150kHz to 80MHz
Enclosure Type Rating
None (open-style)
Conductors
Wire Size
Category
1
12AWG (4mm
2
) stranded copper wire rated at 75°C or higher
3/64 inch (1.2mm) insulation maximum
Established by installed module
Certifications (when product
is marked)
2
C
-UR-
US
UL Recognized Component Industrial Control Equipment,
certified for US and Canada (1794-TB37EXD4VM8,
1794-TB37EXD4CM8 and 1794-TB62EXD4X15)
CSA CSA Accepted Component for Process Control Equipment
CE
European Union 89/336/EEC EMC Directive,
compliant with:
EN 61000-6-4; Industrial Emissions
EN 50082-2; Industrial Immunity
EN 61326; Meas./Control/Lab., Industrial Requirements
EN 61000-6-2; Industrial Immunity
C-Tick - Australian Radiocommunications Act compliant with
AS/NZS CISPR 11, Industrial Emissions
