Module description – Rockwell Automation 1769-OV32T Compact Module User Manual
Page 3

Compact 32-point Solid-state 24V dc Sink Output Module 3
Publication 1769-IN073B-EN-P - September 2005
Module Description
Item Description
1
bus lever
(with locking function)
2a
upper panel mounting tab
2b
lower panel mounting tab
3
I/O diagnostic LEDs
4
module door with terminal
identification label
5a
movable bus connector
with female pins
5b
stationary bus connector
with male pins
6
nameplate label
7a
upper
tongue-and-groove slots
7b
lower
tongue-and-groove slots
8a
upper DIN rail latch
8b
lower DIN rail latch
9
write-on label (user ID tag)
10
MIL-C-83503 connector
31563A-M
1769-OV32T
+VDC1
+VDC1
DC COM 1
DC COM 2
DC COM 2
DC COM 1
OUT 0
OUT 1
OUT 2
OUT 3
OUT 4
OUT 5
OUT 6
OUT 7
OUT 8
OUT 9
OUT 10
OUT 11
OUT 12
OUT 13
OUT 14
OUT 15
+VDC2
+VDC2
OUT 16
OUT 17
OUT 18
OUT 19
OUT 20
OUT 21
OUT 22
OUT 23
OUT 24
OUT 25
OUT 26
OUT 27
OUT 28
OUT 29
OUT 30
OUT 31
1
2a
3
4
10
2b
8a
7a
7a
5a
9
7b
7b
8b
5b
6
