1788-6.5.1 - January 1999
Appendix
A
Specifications
Table A.A Linking Device Specifications
Type Specifications
Environmental Operating Temperature: 0 to 60° C (32 to 140° F)
Storage Temperature: -40 to 85° C (-40 to 185° F)
Relative Humidity: 5 to 90% (non-condensing)
Vibration Operating - 2Gs each axis
Tested 2Gs @ 10 - 500 Hz per IEC 68-2-6
Communication ControlNet - redundant media and network access port
F OUNDATION Fieldbus H1, 2 independent channels
LAS on both channels
Time Master on both channels
Power Requirements 11-30V dc; 270 mA @ 24V dc (typical)
Indicators Module Status
Fieldbus Status, 1 each channel
ControlNet Status, 1 each connection
Connectors ControlNet - BNC connectors
Network Access Port - RJ45
Fieldbus - 9-pin sub-D connectors
Conductors/Wire Size/Category
Category 2
1
Mounting 35 mm DIN rail
ControlNet Channel Selection two 10-position rotary switches
Agency Certification
(when product is marked)
• Information Technology Equipment
• Industrial Control Equipment
• Class I, Div. 2, Groups A, B. C, D
Hazardous Location
• EN 50082-1, 2
• EN 55022, Radiated Emission Class B
• EN 61131-2
FCC Part 15, SubPart B
1 Refer to the Industrial Automation Wiring and Grounding Guidelines for Noise Immunity, publication 1770-4.1.
C US
