CompactBlock Distributed I/O on Remote I/O Series D 11
Publication 1791R-IN002B-EN-P - August 2003
Mount the Block(s)
The base and expansion modules mount to a panel or DIN rail which must be
grounded before installing the module(s).
Base Module Mounting
Install the CompactBlock base module on a panel or DIN rail.
DIP
Switch
No. Description ON OFF
SW2
1 Comm Rate
00=57.6K 01=115.2K
10=230.4K 11=230.4K
2 Comm Rate
3 N/A
4 Hold Last State Hold Last State Output Reset
5 Processor Restart/Lockout Lockout Restart
6 Last I/O Last Rack Not Last Rack
7 Filter Speed Setting
00=2ms 10=4ms
01=8ms 11=16ms
8 Filter Speed Setting
!
WARNING
When used in a Class I, Division 2, hazardous
location, this equipment must be mounted in a suitable
enclosure with proper wiring method that complies
with the governing electrical codes.
