Page 14

14 1738 ArmorPOINT I/O EtherNet/IP Adapter
Publication 1738-IN031A-EN-P - July 2013
Inrush current, max
6 A for 10 ms
Input overvoltage protection
Reverse polarity protected
POINTBus output current, max
5V DC @ 1.0A
Auxiliary power cable
(1)
Standard cordset (single-ended), for example Allen-Bradley part
number 889N-F4AFC-6F or 889N-R4AFC-6F.
Standard patchcord (double-ended), for example, Allen-Bradley
part number 889N-F4AFNU-6F or 889N-F4AFNV-6F.
Interruption
Output voltage stays within specifications when input drops out
for 10 ms @ 10V with max load
(1)
Refer to publicat
Ethernet Communication
Attribute
Value
Ethernet communication rate
10/100 Mbits/s, half or full-duplex
Ethernet ports
1
Ethernet network topologies supported
Star, Tree
Ethernet connectors
M12, D code, female, with Ethernet keying
Ethernet cable
Category 5:
shielded or unshielded
General Specifications
Attribute
Value
Indicators
3 red/green status indicators (on CPU):
– Module status
– Network status
– POINTBus status
1 green status indicator on CPU:
– Network activity
2 green power supply status indicators on DC-DC Converter:
– System power (5V DC to POINTBus Out)
– Field power (24V DC from Field In)
Power consumption, max
8.1 W @ 28.8V DC
Power dissipation, max
2.8 W @ 28.8V DC
Input overvoltage protection
Reverse polarity protected
Power Supply
Attribute
Value
