24 SmartGuard 600 Controllers
Publication 1752-IN001C-EN-P - January 2009
Specifications
SmartGuard 600 Controllers - 1752-L24BBB, 1752-L24BBBE
Attribute
1752-L24BBB
1752-L24BBBE
Dimensions (HxWxD), approx.
99.0
(4)
x 99.4 x 131.4 mm
(5)
(3.90
(4)
x 3.91 x 5.18
(5)
in.)
99.0
(4)
x 113.0 x 131.4
(5)
mm
(3.90
(4)
x 4.48 x 5.18
(5)
in.)
Weight, approx.
460 g (1.23 lb)
575 g (1.54 lb)
DeviceNet current load, max
15 mA @ 24V DC
Supply voltage
(1)
20.4…26.4V DC (24V DC, -15…10%)
Inrush current - unit power supply
4.8 A peak for 600
μ
s @ V0/G0
Inrush current - safety input power
supply
2.6 A peak for 3 ms @ V1/G1
DeviceNet voltage range
11…25V DC
Current consumption
(V0 - internal logic circuit)
230 mA @ 24V DC
280 mA @ 24V DC
Overload protection
Shut down of the affected output with cyclic reconnecting
Isolation voltage
50V, Functional insulation type
Tested at 600V AC for 60 s, between all groups
Wire type
Copper
Wiring category
(2)
2 - on power, signal, and
communication ports
2 - on power, 1 - on signal, 1 -
communication ports
Wire size
For power supply and I/O, use 0.2…2.5 mm
2
(12…24 AWG) solid wire,
or 0.34…1.5 mm
2
(16…22 AWG) standard flexible wire. Before
connecting, prepare standard wires by attaching ferrules with plastic
insulation collars (DIN 46228-4 standard compatible)
For Ethernet connections:
RJ45 connector according to IEC 60603-7, 2 or 4 pair Category 5e
minimum cable according to TIA 569-B.1 or Category 5 cable according
to ISO/IEC 24701
I/O terminal screw torque
0.56…0.79 N•m (5…7 lb•in)
North American temperature code
T4A
Input type
Current sinking
Voltage, on-state input, min
11V DC
Voltage, off-state input, max
5V DC
Current, off-state input, max
1 mA
Input current
4.5 mA
Input impedance
2.6 k
Ω
