Replace the adapter – Rockwell Automation 1734-AENTR POINT I/O 2 Port EtherNet/IP Adapter User Manual
Page 12
12 POINT I/O 2 Port Ethernet Adapter
Publication
1734-IN040B-EN-P - December 2009
Refer to publication POINT I/O Ethernet Adapter User Manual,
r more information.
Replace the Adapter
Use these procedures to install a replacement adapter to an existing
system.
1. Disconnect the Ethernet connector(s) from the adapter.
2. Pull up on the RTB removal handle to remove the terminal
block.
3. Remove the adjacent module from its base.
4. Use a small bladed screwdriver to rotate the DIN rail locking
screw to a vertical position. This releases the locking
mechanism.
5. Lift straight up to remove.
DHCP Enabled and Not Enabled
If DHCP is
Then the Adapter
Enabled
Asks for an address from a DHCP server. The DHCP server also assigns
other Transport Control Protocol (TCP) parameters
Not enabled
Uses the IP address (along with other TCP configurable parameters)
stored in nonvolatile memory
