Rockwell Automation 1738-AENT ArmorPoint EtherNet/IP Adapter, Series A User Manual
Page 11
Publication 1738-IN017B-EN-E - March 2005
ArmorPoint EtherNet/IP Adapter, Series A 11
PointBus Status
Off
Device not powered - check module status indicator.
Flashing Red/Green
Recoverable fault has occurred:
- at power up, the number of expected modules does not equal
the number of modules present
- a module is missing
- node fault (I/O connection timeout).
Red
Unrecoverable fault has occurred:
- the adapter is bus off
- controller in program/idle mode
- Ehternet cable open.
Green
Adapter online with connections established (normal operation,
run mode).
System Power
Off
Not active - field power is off or dc-dc converter problem.
Green
System power on - dc-dc converter active (5V).
Adapter Power
Off
Not active - field power is off.
Green
Power on - 24V present.
Indication
Indication
Probable Cause
