POINTBlock dc 16 Input Module 9
Publication 1734D-IN002A-EN-P - April 2001
Specifications
Specifications - 1734D-IB16, -IB16S
Input Specifications - IEC 3+ 24V dc Input Compliant
Number of Channels 16 input channels
ON-State Voltage Range 10V dc min
24V dc nominal
28.8V dc max
ON-State Current 2.5mA min
6.3mA nominal @ 24V dc
7.6mA max
OFF-State Voltage 5V dc max
OFF-State Current 1.5mA min
Input Impedance 4.7K
Ω
max (3.6K
Ω
nominal)
Input Filter Time
OFF to ON
ON to OFF 0.5ms hardware + (0 - 65ms selectable)
0.5ms hardware + (0 - 65ms selectable)
General Specifications
Pointbus Output Current 1A max @ 5V dc output power
DeviceNet Current 95mA maximum for POINTBlock
350mA for maximum with expansion of
12 POINT I/O modules
Number of POINT I/O
Expansion Modules 12 maximum at expansion port
Isolation Voltage 850V dc for 1s between user power and DeviceNet
Indicators 1 red/ green module status indicator
1 red/green network status indicator
16 yellow I/O status indicators
Power Dissipation 2.0W maximum @ 24V dc
Power Consumption 8.2W maximum @ 24V dc
Field Power Bus
Supply Voltage
Voltage Range
Supply Current 24V dc nominal
10-28.8V dc
10A max
Dimensions Inches
(Millimeters)
3.00H x 2.36W x 5.25L
(76.2 Hx 60.0W x 133.4L)
