6 POINTBlock dc 16 Input Module
Publication 1734D-IN002A-EN-P - April 2001
Note: When connecting more than 1 wire in a termination point,
make sure that both wires are the same gauge and type.
Channel Input Terminal Common Voltage
Remote Termination Block 0
Field Power Block No connections to terminals 0, 1, 2 and 3
Vin (12/24V dc) 6 and 7
Common 4 and 5
Remote Termination Block 1
0 0 4 6
1 1 5 7
2 2 4 6
3 3 5 7
Remote Termination Block 2
4 0 4 6
5 1 5 7
6 2 4 6
7 3 5 7
Remote Termination Block 3
8 0 4 6
9 1 5 7
10 2 4 6
11 3 5 7
Remote Termination Block 4
12 0 4 6
13 1 5 7
14 2 4 6
15 3 5 7
Connect common on 3-wire proximity switches.
12/24V dc is supplied through the internal power bus.
