28 ControlLogix-XT ControlNet Interface Module
Publication 1756-IN634A-EN-P - April 2009
Any Keeper:
Unconfigured The network configuration
data maintained in flash
memory by the keeper object
has been erased or corrupted. Perform any of these steps:
· Use RSNetWorx software to
download or update the
keeper object in the module.
· See Reset the Module to
the Original Factory
Settings, on
page 12 .
Keeper:
Unconfigured
(data format
changed) The network configuration
data maintained in flash
memory by the keeper object
is in a format incompatible
with the current revision of
firmware. Perform any of these steps:
· Use RSNetWorx software to
download or update the
keeper object in the module.
· See Reset the Module to
the Original Factory
Settings, on
page 12 .
Keeper:
Unconfigured
(slot
changed) After the keeper object’s
network-configuration data
was downloaded, the module
was moved to a different spot
in the chassis. Perform any of these steps:
· Return the module to the
proper slot.
· Use RSNetWorx software to
download or update the
keeper object in the module.
· See Reset the Module to
the Original Factory
Settings, on
page 12 .
Keeper:
Unconfigured
(net address
changed) The network address switches
on the module have been
changed since the keeper
object’s network-configuration
data was downloaded. Perform any of these steps:
· Return the network address
switches to their original
setting.
· Use RSNetWorx software to
download or update the
keeper object in the module.
· See Reset the Module to
the Original Factory
Settings, on
page 12 .
OK
Indicator Display Cause Recommended Action
