18 Getting Started with ProcessLogix R500.1
Publication 1757-QS500A-EN-P - October 2002
Assigning the Control Module to the CEE
To assign the Control Module for the PID loop to the CEE:
1. From Control Builder, select Tools⇒Execution Environment Assignment.
2. On the Controller Assignments window, click the CMs/SCMs tab in the in the
Available Modules box.
3. Select FIC102 from the Available Modules box.
4. Select the CEE0101 from the CEE/Link box and click Assign.
The FIC102 module is displayed in the Assigned Modules box.
5. Close the Execution Environment Assignment window.
Building the PID Loop
To develop the PID loop:
1. In the Project tab, open the Control Module by double-clicking FIC102.
2. Click the Library tab.
3. Display the available function blocks by clicking the + to the left of the appropriate
library in the tree display.
4. Click the desired block, then drag and drop it onto the your diagram.
5. Rename the block by double-clicking the block to bring up the Parameters window.
6. Add the following function blocks to the Control Module:
In this library:
Choose this function block:
Rename:
DATAACQ
DATAACQ
DACA
IOCHANNEL
AICHANNEL
AI00
IOCHANNEL
AOCHANNEL
AO00
REGCTL
PID
PIDA
UTILITY
NUMERIC
NUMERIC
