ArmorBlock MaXum 12 Input/ 4 Output Module Series B 9
Publication 1792D-IN004B-EN-P - August 2000
The DeviceNet Network uses advanced network technology,
producer/consumer communication, to increase network
functionality and throughput. Visit our web site at
http://www.ab.com/networks for producer/consumer technology
information and updates.
Troubleshoot with the Indicators
This module has the following indicators:
• Network/Module status indicator
• Logic status indicator
• Auxiliary Power indicator
• Individual I/O status indicators
Byte Bit Description
Produces 2 00-01
ISC
02-07
Off Wire
Input short circuit fault (ISC): (ISC-E indicates a short
circuit fault for connector E.
Input short circuit fault ((ISC): (ISC-F indicates a short
circuit fault for connector F.
Input off wire fault (OW): OW-A indicates an off-wire fault
for connector A.
Input off wire fault (OW): OW-B indicates an off-wire fault
for connector B.
Input off wire fault (OW): OW-C indicates an off-wire fault
for connector C.
Input off wire fault (OW): OW-D indicates an off-wire fault
for connector D.
Input off wire fault (OW): OW-E indicates an off-wire fault
for connector E.
Input off wire fault (OW): OW-F indicates an off-wire fault
for connector F.
Produces 3 00-03
OFLT0-3
06
04, 05, 07
Output no load or overload fault (OFLT): - When the bit is
set (1) an output fault has occurred. OFLT0 corresponds to
output 0, OFLT1 corresponds to output 1, OFLT2
corresponds to output 2, OFLT3 corresponds to output 3
Output Power Fault (OPWR): When the bit is set (1)
Auxiliary Power is not present.
RSVD = Reserved
Consumes 0 00-03
04-07
Output bits: When the bit is set (1), the output will be
turned on. Bit 00 corresponds to output O0, bit 01
corresponds to output 01, bit 02 to output 02, bit 03 to
output 03.
RSVD = Reserved
