Rockwell Automation 1790D-XXXX DeviceNet 32 Point Digital Base Terminal Block CompactBlock LDX I/O Series B User Manual
Page 17

DeviceNet 32 Point Digital Base Terminal Block CompactBlock LDX I/O 17
Publication
1790-IN014A-EN-P - March 2008
Output signal delay, off to on, max
0.5 ms
Output signal delay, on to off, max
1.0 ms
Output current rating, output, max
0.5 A
Output current rating, common, max
4.0 A
Field power dissipation
2.76 W @ 28.8V dc
DC field power
Supply voltage - 24V dc nom
Voltage range - 10…28.8V dc
1790D-T16BV16V, 1790D-T16BV16B
Attribute
Value
Number of inputs, non-isolated
16 points , sinking or sourcing
Voltage, off-state input, max
5.0V dc
Voltage, on-state input, max
28.8V dc
Voltage, on-state input, nom
24V dc
Voltage, on-state input, min
9.6V dc
Current, on-state, max
8 mA per channel @ 28.8V dc
Current, on-state, min
1 mA per channel
Input impedance, nom
4.8 kohm
Number of outputs, non-isolated
16 points, sinking (1790D-T16BV16V)
16 points, sourcing (1790D-T16BV16B)
Voltage, on-state output, max
28.8V dc (catalog number 1790D-T16BV16B only)
Voltage, on-state output, nom
24V dc (catalog number. 1790D-T16BV16B only)
Voltage, on-state output, min
10V dc (catalog number 1790D-T16BV16B only)
Voltage, on-state drop, max
0.5V dc
Output current rating, output, max
0.5 A
Output current rating, common, max
4.0 A
1790D-TOV32, 1790D-TOB32
Attribute
Value
