Specifications, Specifications 16 – Rockwell Automation 1790D-XXXX DeviceNet 32 Point Digital Base Terminal Block CompactBlock LDX I/O Series B User Manual
Page 16
16 DeviceNet 32 Point Digital Base Terminal Block CompactBlock LDX I/O
Publication
1790-IN014A-EN-P - March 2008
Specifications
Universal DC Input Base Block - 1790D-T32BV0
Attribute
Value
Number of inputs
32
Input type
Sink, source 24V dc
Voltage, off-state input, max
5V dc
Voltage, on-state input, max
28.8V dc
Voltage, on-state input, nom
24V dc
Voltage, on-state input, min
9.6V dc
Current, off-state input, max
1.5 mA @ 5V dc
Current, on-state input, max
8 mA @ 28.8V dc per channel
Input impedance, nom
4.8 kohm
Field power dissipation
3.68 W max @ 28.8V dc
DC field power
Supply voltage - 24V dc nom
Voltage range - 10…28.8V dc
1790D-TOV32, 1790D-TOB32
Attribute
Value
Number of outputs, nonisolated
32, sinking (1790D-TOV32)
32, sourcing (1790D-TOB32)
Voltage, off-state output, max
28.8V dc
Voltage, on-state output, max
28.8V dc
Voltage, on-state output, nom
24V dc
Voltage, on-state output, min
10V dc
Voltage, on-state drop, max
0.5V dc
Current, on-state output, min
1 mA per channel
Leakage, off-state, max
0.5 mA
