System start-up chapter 4 – Rockwell Automation 1772-LV,D17726.6.1 A and I MNL MINI-PLC-2/15 PROCESSO User Manual
Page 63
System Start-Up
Chapter 4
4Ć3
Figure 4.1
I/O and Industrial Terminal Status Indicators
10134ĆI
Module Indicator
Illuminates when
Device is On
110
11
112
12
110
13
Diaplay Intensifies
TRUE Instruction
Industrial Terminal
(Cat. No. 1770ĆT3)
Input Device
(On or Off)
Input module
Indicator
10134ĆI
Hardware/Indicator Comparison Procedures
WARNING: Machine motion during this procedure can cause
injury to personnel or damage to equipment. Disconnect any
device that might cause machine motion to occur when energized.
