20 DeviceNet Digital Base D-shell Block CompactBlock LDX I/O
Publication
1790-IN013A-EN-P - September 2006
Off-state Leakage, Max
0.5 mA
Output Signal Delay,
Off to On
0.5 ms max
Output Signal Delay,
On to Off, Max
1.0 ms
Output Current Rating
0.5 A max per output, 4.0 A max per common
Field Power Dissipation
2.76 W @ 28.8V dc
Isolation Voltage
50V dc (continuous), reinforced insulation type,
tested at 1250V ac for 60 s, I/O to system
Environmental Specifications Common To All Base Blocks in This Publication
Attribute
Value
North American Temp Code
T5
Operating Temperature
IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock)
0...55 °C (32...131 °F)
Storage Temperature
IEC60068-2-1 (Test Ab, Unpackaged Nonoperating Cold)
IEC60068-2-2 (Test Bb, Unpackaged Nonoperating Dry Heat)
IEC60068-2-14 (Test Na, Unpackaged Nonoperating Thermal
Shock)
-40...85 °C (-40...185 °F)
Relative Humidity
IEC60068-2-30 (Test Db, Unpackaged Damp Heat)
5...90% noncondensing
Vibration
IEC 60068-2-6 (Test Fc, Operating) 2 g @ 10…500 Hz
Shock, Operating
IEC60068-2-27 (Test Ea, Unpackaged Shock) 10 g
Shock, Nonoperating
IEC60068-2-27 (Test Ea, Unpackaged Shock) 30 g
Emissions
CISPR 11: Group 1, Class A
ESD Immunity
IEC6100-4-2: +8 kV air discharges
1790D-OV16 and 1790D-OB16 dc Output Base Block
Attribute
Value
