Cable specifications – Rockwell Automation 1757-SRC1_3_10_50_100 ProcessLogix Redundancy Module Cable Installation Instructions User Manual
Page 3
Redundancy Module Cable 3
Publication 1757-IN014B-EN-P - November 2002
5. Close the first redundancy module door.
6. Open the door on the second redundancy module.
7. Plug the remaining cable connector end to the second redundancy module.
Cable Specifications
TIP
The connectors on the cable and the module are keyed
for correct installation.
Redundancy
Cable Interfaces
connector
ST-type (fiber-optic)
cable type
62.5/125 micron multi-mode fiber-optic cable
channels
one (transmit and receive fiber)
ground isolation
N/A (fiber-optic interface)
30823-M
