17
Publication 1790-IN009B-EN-P - April 2003
Important: Input and output wiring must be in accordance
with Class 1, Division 2 wiring methods and in
accordance with the authority having
jurisdiction.
General Specifications
PROFIBUS Power Supply voltage - 24V dc nominal
Voltage range - 19.2-28.8V dc
Power dissipation - 1.2W maximum @ 28.8V dc
Field Power Supply voltage - 24V dc nominal
Voltage range - 19.2-28.8V dc
Power dissipation - 1.7W @ 28.8V dc
Isolation I/O to logic: photocoupler isolation
Isolation voltage: 1250V ac rms
Wiring Terminal block (M3.0)
- screw torque: 7 inch-pounds
maximum (use copper or copper-clad
aluminum conductors
