ArmorBlock 4 Output Module 30
Publication 1792-5.4 – October 1996
”This connection contains status from outputs at bits 0–3.”;
Output1 =
1,
$ The size in bytes that this connection consumes.
4, $ Only the four least significant bits of this
$ connection are used.
0x0001, $ Only Polled I/O is compatible.
”OB4E Consumption Data”,$ Name of Connection.
6,
$ Path length.
”20 04 24 21 30 03”, $ Path to I/O Consumption Assembly.
$$$$$$$$$$ Help string $$$$$$$$$$$
”This connection contains data for four outputs.”;
[ParamClass]
MaxInst = 8;
$ 4 configurable and 4 read–only parameters.
Descriptor = 0x09; $ Stub param instances in eeprom.
CfgAssembly = 0x67; $ The config assembly is instance #103 of assy obj.
[Params]
$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$
$$$$$$$$$$
Param1 =
$ Disable Autobaud
0, $ reserved
6, $ Link Path Size
”20 03 24 01 30 64”, $ Link Path to disable autobaud attribute.
0x0002, $ No support for settable path, scaling, scaling
$ links, or real time update of value.
$ Value is gettable and Settable.
$ Enumerated strings are supported.
4, $ Data Type – boolean
1, $ Data Size
”Autobaud”, $ Parameter Name
””, $ Units String
$$$$$$$$$$ Help string $$$$$$$$$$$
”Enable takes effect after next powerup. Disable is required to set fixed baud rate, no
power cycle is required.”,
0,1,0,
$ Min, Max, and Default values
1,1,1,0,0,0,0,0,0; $ Not Used
$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$
$$$$$$$$$$
Param2 =
$ Fault State selection
0, $ reserved
6, $ Link Path Size
”20 1E 24 01 30 07”, $ Link Path to DOG object’s fault state attribute.
0x0002, $ No support for settable path, scaling, scaling
$ links, or real time update of value.
$ Value is gettable and Settable.
$ Enumerated strings are supported.
4, $ Data Type – boolean
1, $ Data Size
