Rockwell Automation 1738-IE2VM12 ArmorPoint 24V dc Analog Input Modules, Series A - Manual (Page 11)

Publication 1738-IN003B-EN-E - June 2005
ArmorPoint 24V dc Analog Input Modules, Series A 11
Input Data Format Signed integer
General Specifications
Calibration
Factory calibrated
Dimensions, Metric 120H x 72W x 42D
Dimensions, Imperial 4.72H x 2.83W x 1.65D
External dc Power Supply Voltage, Nom. 24V dc
External dc Power Supply Voltage Range 10…28.8V dc
External dc Power Supply Current 1738-IE2C - 10 mA @ 24V dc
1738-IE2V - 15 mA @ 24V dc
Indicators 1 green/red module status indicator, logic side
1 green/red network status indicator, logic side
2 green/red input status indicators, logic side
Isolation Voltage
(continuous-voltage withstand rating)
50V rms
Tested at 1250V ac rms for 60s
Keyswitch Position 3
Mounting Base Screw Torque #8 screw, 7.5 in. lbs. in Aluminum, 16 in. lbs. in Steel
Overvoltage Protection, Input Fault protected to 28.8V dc
PointBus Current 75 mA @ 5V dc
Power Dissipation, Max. 1738-IE2C - 0.6 W @ 28.8V dc
1738-IE2V - 0.75 W @ 28.8V dc
Thermal Dissipation, Max. 1738-IE2C - 2.0 BTU/hr. @ 28.8V dc
1738-IE2V - 2.5 BTU/hr. @ 28.8V dc
Weight, Metric 0.29 kg
Weight, Imperial 0.64 lb
Operating Temperature IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock):
-20 … 60 °C (-4 … 140 °F)
Storage Temperature IEC 60068-2-1 (Test Ab, Un-packaged Non-operating Cold),
IEC 60068-2-2 (Test Bb, Un-packaged Non-operating Dry Heat),
-40 … 85 °C (-40 … 185 °F)
Relative Humidity IEC 60068-2-30 (Test Db, Un-packaged Non-operating Damp Heat):
5…95% non-condensing
Shock IEC60068-2-27 (Test Ea, Unpackaged Shock):
Operating 30 g
Non-operating 50 g
Vibration IEC60068-2-6 (Test Fc, Operating):
5 g @ 10-500 Hz
ESD Immunity IEC 61000-4-2:
6 kV contact discharges
8 kV air discharges
Radiated RF Immunity IEC 61000-4-3:
10V/m with 1 kHz sine-wave 80% AM from 30 MHz to 2000 MHz
10V/m with 200 Hz 50% Pulse 100% AM at 900 Mhz
10V/m with 200 Hz 50% Pulse 100% AM at 1890 Mhz
EFT/B Immunity IEC 61000-4-4:
±3 kV at 5 kHz on signal ports
Surge Transient Immunity IEC 61000-4-5:
±2 kV line-earth(CM) on shielded ports
