10 ArmorPoint 24V dc Analog Input Modules, Series A
Specifications
Indication
Probable Cause
I/O Status
Off
Module in CAL mode
Solid Green
Normal (channel scanning inputs)
Flashing Green
Channel being calibrated
Solid Red
No power or major channel fault
Flashing Red
Channel at end of range (over or under)
ArmorPoint Analog Input Modules
Number of Inputs
2
Input Point Density
2 single-ended, non-isolated
Input Voltage Signal Range
1738-IE2V
0…10V (user configurable) (-0.0V under, +0.5V over)
+10V user configurable (-0.5V under, +0.5V over)
Input Current Signal Range
1738-IE2C
4…20mA
0…20mA
Absolute Accuracy
1
0.1% Full Scale @ 25°C
Accuracy Drift w/Temp., Current Input
1738-IE2C - 30 ppm/°C
Accuracy Drift w/Temp., Voltage Input
1738-IE2V - 5 ppm/°C
Digital Filter Time Constant
0…10,000 ms (default = 0 ms)
Input Common Mode Rejection Ratio
120 dB
Input Conversion Type
Delta Sigma
Input Impedance
1738-IE2C - 60
Ω
1738-IE2V - 100 K
Ω
Input Normal Mode Rejection Ratio
-60 dB
-3 db
Notch filter
15.7 Hz @ Notch = 60 Hz
13.1 Hz @ Notch = 50 Hz
65.5 Hz @ Notch = 250 Hz
131 Hz @ Notch = 500 Hz
Input Resistance
1738-IE2C - 60
Ω
1738-IE2V - 200 K
Ω
Input Resolution, Bits
1738-IE2C - 16 bits - over 0…21mA; 0.32
µA/cnt
1738-IE2V - 15 bits plus sign; 320
µV/cnt in unipolar or bipolar mode
Input Step Response (per channel)
70 ms @ Notch = 60 Hz (default)
80 ms @ Notch = 50 Hz
16 ms @ Notch = 250 Hz
8 ms @ Notch = 500 Hz
Input Update Rate (per module)
100 ms @ Notch = 60 Hz (default)
120 ms @ Notch = 50 Hz
24 ms @ Notch = 250 Hz
12 ms @ Notch = 500 Hz
