4 Sinking Input / 4 Output Module 9
Publication 1792D-5.26 - January 1999
Specifications
4 Input / 4 Output Module - Cat. No. 1792D-4BT4LP
Sinking Input Specifications Max Min
Inputs per block 4 - 3 wire or dry contact PNP devices or 2 - 4 wire
PNP devices
Sensor Source Current (per input) 50mA -
On-state Voltage 25V dc 10V dc
On-state Current 10mA 2mA
Off-state Voltage 5V dc
Off-state Current 1.5mA
Sourcing Output Specifications Max Min
Outputs per block 4 sourcing outputs labeled O0, O1, O2, and O3
Output Auxiliary Voltage 30V 10V
On-state Voltage Drop 1V -
On-state Current 0.3A -
Off-state Leakage 1.5mA -
Module Current (all outputs) 1.2A -
Surge Current - for 10ms,
repeatable every 2s 0.6A -
No Load Sense Current (On-state) 0.18A -
General Specifications
Indicators Network Status - red/green
Module Status - red/green
Auxiliary Power - green
Point LED - yellow
Communication Rate • 125Kbps @ 500 meters(1600 feet) for thick
cable, flat media length 375 meters
• 250Kbps @ 200 meters(600 feet) for thick cable,
flat media length 150 meters
• 500Kbps @ 100 meters (330 feet) for thick
cable, flat media length 75 meters
DeviceNet Power Voltage
Current 25V dc
125mA (no sensors)
300mA (full load)
11V dc
Auxiliary Power Voltage
Current 30V dc
1.2A max
10V dc
1.2A max
Dimensions (assembled to base)
inches - (Millimeters) 1.023H x 2.7w x 4.72D
(26)H x (68.5)W x (120)D
