Using This Manual P–2
Publication 1771Ć6.5.129 - March 2000
Appendices
Appendix C Data Formats Information on BCD, signed magnitude (12-bit) binary, and 2's
complement binary
Appendix D Block Transfer with Mini-PLC-2
and Mini-PLC-2/20
How to use GET-GET instructions for block transfer with Mini-PLC-2
and Mini-PLC-2/20 processors
Appendix E 2 and 4-wire RTD Sensors Shows wiring connections for 2 and 4-wire sensors
Appendix F Differences Between Series A, B,
C and D
Identifies major differences between the series A, B, C, and D of the
RTD module.
Appendix G CSA Hazardous Location
Approval
Certification information for CSA
You can install your input module in any system that uses
Allen–Bradley programmable controllers with block transfer
capability and the 1771 I/O structure.
Contact your nearest Allen–Bradley office for more information
about your programmable controllers.
This input module can be used with any 1771 I/O chassis.
Communication between the discrete analog module and the
processor is bidirectional. The processor block–transfers output data
through the output image table to the module and block–transfers
input data from the module through the input image table. The
module also requires an area in the data table to store the read block
and write block data. I/O image table use is an important factor in
module placement and addressing selection. The module’s data table
use is listed in the following table.
Compatibility and Use of Data Table
Catalog
Number
Use of Data Table
Input Output Read Write
Image Image Block Block
Bits Bits Words Words
Compatibility
Addressing Chassis
1/2 -slot 1-slot 2-slot Series
1771-IR
Series D
8 8 8/9 14/15 Yes Yes Yes A and B
A = Compatible with 1771-A1, A2, A4 chassis.
B = Compatible with 1771-A1B, A2B, A3B, A4B chassis.
Yes = Compatible without restriction
No = Restricted to complementary module placement
You can place your input module in any I/O module slot of the I/O
chassis. You can put:
•
two input modules in the same module group
•
an input and an output module in the same module group.
Related Products
Product Compatibility
