Rockwell Automation 1405-M620 Operating Instructions User Manual
Page 12

Publication 1405-IN002C-EN-P - November 2004
12 Bulletin 1405 (M620) Operating Instructions
Table 6 Modbus Memory Map
Register
Byte Low
Metered Value
Data Type
0
0
L1-N voltage
WORD
1
2
L2-N voltage
WORD
2
4
L3-N voltage
WORD
3
6
L1-L2 voltage
WORD
4
8
L2-L3 voltage
WORD
5
10
L3-L1 voltage
WORD
6
12
I1
WORD
7
14
I2
WORD
8
16
I3
WORD
9
18
I1 peak
WORD
10
20
I2 peak
WORD
11
22
I3 peak
WORD
12
24
I1 average
WORD
13
26
I2 average
WORD
14
28
I3 average
WORD
15
30
Cos1 (power factor)
WORD
16
32
Cos2
WORD
17
34
Cos3
WORD
18
36
P1 real power
DWORD
19
38
20
40
P2 real power
DWORD
21
42
22
44
P3 real power
DWORD
23
46
24
48
S1 apparent power
DWORD
25
50
26
52
S2 apparent power
DWORD
27
54
28
56
S3 apparent power
DWORD
29
58
30
60
E1 real energy
DWORD
31
62
32
64
E2 real energy
DWORD
33
66
