Bul. 937C HART Loop Converter Installation Instructions
Changing the Custom Tag of HART Variables
1.
Select the HART variable for which you would like to change the
custom tag.
2.
Press the
OK button.
3.
Select the
Custom Tag menu.
The device displays:
if a value has not been defined: the insert mark and the symbol
If a value is defined: the insert mark on the first character, the following character,
and the symbol
4.
To select one of eight possible positions for the insert mark before the symbol
, press the or button.
5.
Confirm your selection with
OK.
The insert mark flashes.
6.
To select a character, press the or button.
7.
Confirm your entry with
OK.
8.
Repeat steps 4 and 7, until all characters have been entered. You can also define
spaces.
9.
To select the symbol , press the or button.
10. Confirm your entry with
OK.
The new value for
Custom Tag has been stored.
Canceling the Value Input for HART Variables You
can cancel the value entry at any time.
Press the
ESC button.
25
24
