Bul. 937C HART Loop Converter Installation Instructions
Entering a Numerical Value
1.
Select the parameter for which you want to enter the numerical value.
2.
Press the
OK button.
The current value from the mantissa and exponent flashes.
3.
Press the
OK button.
With positive numbers, the first digit of the mantissa
flashes. With negative numbers, the minus sign flashes.
4.
To change the value in steps from 0 to 9, press the or button.
To enter a minus sign, press the until the first digit is less than 0.
5.
Confirm your selection with
OK.
The next digit of the mantissa flashes.
6.
Repeat steps 4 and 5, until all digits have been entered.
7.
Confirm your entry with
OK.
The position of the decimal point flashes.
8.
Press the or button to specify the position of the decimal
point.
9.
Confirm your entry with
OK.
The exponent flashes.
10. To specify the value of the exponent, press the or button. You can select
the exponents from E-33 to E33 in increments of three.
11. Confirm your entry with
OK.
The new value is stored.
23
