TECHNICAL DATA SHEET
BUL. 1606-XLS960EE, 1606-XLS960FE
POWER SUPPLIES
1606-XLS960: Power Supply Instruction Manual
1606-XLS960: Bedienungsanleitung für Stromversorgung
Technical Data
1)
Technische
Daten
1)
XLS960E
XLS960EE
XLS960F
XLS960FE
g
n
u
n
n
a
p
s
s
g
n
a
g
s
u
A
e
g
a
t
l
o
V
t
u
p
t
u
O
nom.
DC 24-28V
DC 24-28V
DC 48-54V
DC 48-54V
Factory Setting at Full Load
Werkseinstellung bei Nennlast
“Single-Use”, typ.
24.1V
24.1V
48.0V
48.0V
Output Current
continuous Ausgangsstrom
dauernd
nom.
40A (24V)
34.3A (28V)
40A (24V)
34.3A (28V)
20A (48V)
17.8A (54V)
20A (48V)
17.8A (54V)
Output Current
short-term (4s)
14)
Ausgangsstrom kurzzeitig (4s)
14)
nom.
60A (24V)
51.5A (28V)
60A (24V)
51.5A (28V)
30A (48V)
26.7A (54V)
30A (48V)
26.7A (54V)
short-term (25ms)
A
5
5
A
5
5
A
0
1
1
A
0
1
1
)
s
m
5
2
(
g
i
t
i
e
z
z
r
u
k
Output Power
continuous Ausgangsleistung
dauernd
nom.
960W
960W
960W 960W
Output Power
short-term (4s)
14)
Ausgangsleistung kurzzeitig (4s)
14)
nom.
1440W
1440W
1440W 1440W
Output Ripple & Noise Voltage
13)
Ausgangswelligkeit
13)
max.
100mVpp
100mVpp
150mVpp 150mVpp
AC Input Voltage
AC Eingangsspannung
nom.
AC 100-240V
15)
-15%/+10%
AC 200-240V
-15%/+10%
AC 100-240V
15)
-15%/+10%
AC 200-240V
-15%/+10%
Input Frequency
Eingangsfrequenz
nom.
50-60Hz
±6%
50-60Hz
±6%
50-60Hz
±6%
50-60Hz
±6%
AC Input Current
3)
AC
Eingangsstrom
3)
typ.
8.6A / 4.5A
- / 4.6A
8.6A / 4.5A
- / 4.6A
Power Factor
3)
r
o
t
k
a
f
s
g
n
u
t
s
i
e
L
3)
typ.
0.99 / 0.99
- / 0.96
0.99 / 0.99
- / 0.96
Allowed Voltage L or N to Earth
Erlaubte Spannung L oder N zu Erde
max.
300Vac
300Vac
300Vac 300Vac
PFC Norm EN 61000-3-2 Class A
PFC Norm EN 61000-3-2 Klasse A
-
Yes / Ja
Yes / Ja
Yes / Ja
Yes / Ja
DC Input Voltage
DC Eingangsspannung
nom.
-
-
- -
Input Inrush Current
3) 4)
Einschaltspitzenstrom
3) 4)
typ.
16A / 9A peak
- / 14A peak
16A / 9A peak
- / 14A peak
Hold-up Time
3)
t
i
e
z
r
e
f
f
u
P
3)
typ.
27ms / 27ms
- / 30ms
27ms / 27ms
- / 30ms
Efficiency
3)
d
a
r
g
s
g
n
u
k
r
i
W
3)
typ.
93.6% / 94.6%
- / 94.6%
93.9% / 95.0%
- / 95.0%
Power Losses
3)
g
n
u
t
s
i
e
l
t
s
u
l
r
e
V
3)
typ.
65.6W / 54.8W
- / 54.8W
62.4W / 50.5W
- / 50.5W
Operational Temperature Range
Betriebstemperaturbereich
nom.
-25°C - +70°C
-25°C - +70°C
-25°C - +70°C
-25°C - +70°C
e
L
g
n
i
t
a
r
e
D
t
u
p
t
u
O
istungsrücknahme
+60°C to +70°C
24W/°C
24W/°C
24W/°C
24W/°C
Storage Temperature Range
Lagertemperaturbereich
nom.
-40°C - +85°C
-40°C - +85°C
-40°C - +85°C
-40°C - +85°C
Humidity
5)
e
t
h
c
u
e
F
5)
IEC 60068-2-30
5 - 95% r.H.
5 - 95% r.H.
5 - 95% r.H.
5 - 95% r.H.
n
e
g
n
i
w
h
c
S
n
o
i
t
a
r
b
i
V
IEC 60068-2-6
1g
1g
1g
1g
n
e
k
c
o
h
c
S
k
c
o
h
S
IEC 60068-2-27
15g 6ms,
10g 11ms
15g 6ms,
10g 11ms
15g 6ms,
10g 11ms
15g 6ms,
10g 11ms
Degree of Pollution
Verschmutzungsgrad
IEC 62103
2
5)
2
5)
2
5)
2
5)
Degree of Protection
Schutzart
EN 60529
IP20
IP20
IP20
IP20
Class of Protection
Schutzklasse
IEC 61140
I
6)
I
6)
I
6)
I
6)
Over-temperature Protection
Übertemperaturschutz
OTP
Yes / Ja
Yes / Ja
Yes / Ja
Yes / Ja
Output Over-voltage Protection
Überspannungsschutz am Ausgang
OVP, max.
32Vdc
32Vdc
60Vdc
60Vdc
Return Voltage Resistance
8)
Rückspeisefestigkeit
8)
max.
35Vdc
35Vdc
63Vdc 63Vdc
Leakage Current
7)
TN/TT-mains
IT-mains
PE- Ableitstrom
7)
TN/TT-Netze
IT-Netze
max.
max.
0.71mA / 1.18mA
1.73mA / 2.82mA
- / 0.75mA
- / 1.74mA
0.71mA / 1.18mA
1.73mA / 2.82mA
- / 0.75mA
- / 1.74mA
Parallel Use
11)
r
a
b
t
l
a
h
c
s
l
e
l
l
a
r
a
P
11)
-
Yes / Ja
Yes / Ja
Yes / Ja
Yes / Ja
Serial Use
12)
r
a
b
t
l
a
h
c
s
n
e
i
r
e
S
12)
-
Yes / Ja
Yes / Ja
Yes / Ja
Yes / Ja
Dimensions
9)
(WxHxD) Abmessungen
9)
(BxHxT)
nom.
125x124x127mm
125x124x127mm
125x124x127mm 125x124x127mm
t
h
c
i
w
e
G
t
h
g
i
e
W
max.
1900g, 4.2lb
1800g, 4lb
1900g, 4.2lb
1800g, 4lb
1) All parameters are specified at 230Vac input voltage, nominal output current, “Single Use”
setting, 25°C ambient and after a 5 minutes run-in time unless otherwise noted.
3) At
120Vac
/
230Vac
4) Input inrush current is electronically limited, temperature independent and is valid for mains
interruptions > 1s
5) Do not energize while condensation is present.
6) PE connection required (Ground).
7) Leakage current at 132Vac, 60Hz / 264Vac, 50Hz
8) Loads such as decelerating motors and inductors can feed voltage back to the output of the
power supply. The figure represents the maximum allowed feed back voltage
9) Depth
without
DIN-rail.
11) Set jumper on the front to “Parallel Use”. A fuse (or diode) on the output is required if more
than three units are paralleled.
12) Use only power supplies of the same type. The total output voltage should not be >150Vdc.
13) 50-Ohm measurement, bandwidth 20MHz
14) BonusPower
®
: The short-term power is available for 4s. After this, the output power will be
automatically reduced to the continuous output power level
15) An output current derating might be necessary at input voltages below 90Vac, see figure 5
1) Alle
Werte
gelten
bei
230Vac
Eingangsspannung, Nennausgangsstrom, „Single-Use“ Modus,
25°C Umgebung und nach einer Aufwärmzeit von 5 Minuten, falls nichts anderes angegeben.
3) bei
120Vac
/
230Vac
4) Der
Einschaltstromstoß
ist
elektronisch begrenzt, temperaturunabhängig und gilt für
Netzunterbrechungen > 1s
5) Nicht betreiben, solange das Gerät Kondensation aufweist.
6) PE
Verbindung
erforderlich.
7) Ableitstrom bei 132Vac, 60Hz / 264Vac, 50Hz
8) Bremsende Motoren oder Induktivitäten können Spannung zum Ausgang des Netzteils
rückspeisen. Der Wert gibt die max. zulässige Rückspeisespannung an.
9) Tiefe
ohne
DIN-Schiene
11) Steckbrücke an der Front des Gerätes auf „Parallel Use“ umstellen. Bei mehr als drei Geräten
wird eine Sicherung oder eine Diode zur Entkopplung benötigt.
12) Nur für gleiche Geräte bis zu einer Gesamtspannung von 150Vdc
13) 50-Ohm Messung, Bandbreite 20MHz
14) BonusPower
®
: Wird dir Kurzzeitleistung für länger als 4s entnommen, reduziert sich die
maximal entnehmbare Ausgangsleistung auf die Dauerleistung
15) Unterhalb 90Vac kann eine Leistungsrücknahme erforderlich sein. Siehe Bild 5
