Chapter
1
1203–5.5 September 1995
Product Description
In this chapter, you will read about:
•
Serial Communications Module features
•
the location of configuration switches
The Serial Communications Module is an optional interface device
designed to provide a direct digital link between serial
communications devices and any device that uses SCANport. The
current list of products that use SCANport includes: 1305, 1336
PLUS, 1336 FORCE, 1394, SMP3 controllers, and 1557 medium
voltage drives. The module connects to these products via
SCANport.
The Serial Communications Module is available in both Open style
(Figure 1.1) and Enclosed (Figure 1.2) type configurations. The
Open style module mounts inside certain drives, depending on drive
size. The Enclosed module mounts independently and can be used
with any SCANport device. The following table provides more
information about the Open and Enclosed styles.
Designation Enclosure Power Supply Source Used With
Open Style Open PC Board Supplied by the drive 1336 PLUS*
1336 FORCE**
1394***
Enclosed IP30 24V DC separately supplied or
120/240V AC separately supplied
1305
1336 PLUS
1336 FORCE
1394
SMP3
Other SCANport products
* 7.5HP and higher sizes only, excluding the AQF and BRF catalog number drives
** 7.5HP and higher sizes with Standard Adapter board only
*** analog 1394 only
Chapter Objectives
Module Description
