Rockwell Automation 931S-C1A2D-OP Passive Isolator User Manual
Page 2

1
1.
General instructions
• Disconnect power prior to installation
• Installation only by Qualified personnel
• Follow all applicable local and national electrical codes
Appropriate safety measures against electrostatic discharge
(ESD) should be taken during assembly and adjustment work on
the 931S-C1A2D-OP.
2.
Application
The Passive Converter 931S-C1A2D-OP is used for the galvanic isolation
and conditioning of current signals and voltage signals. The input signal
can be calibrated via the DIP switch. It is not necessary to adjust the
pre-settable measurement ranges. The output signal is linear to the input
signal.
"Please observe: when switching to a different input range, the output must
be disconnected from the power supply for >10s."
WARNING
WARNING
