1397 Open Chassis Dynamic Brake

2

1397-5.15 March, 1999

These instructions and any accompanying instructions contain the
necessary information to assemble

&

install an Open Chassis 1397

Dynamic Brake. Each kit may be used with one or more of the 1397
drive HP ratings described on the previous page. For additional
information on wire recommendations, brake parameters and related
function blocks, refer to the 1397 User Manual.

Specifications

Duty Cycle

(3) repetitive stops with an average of (1) stop every (10) minutes.

Input Power

DC Power Supplied from 1397 Drive for all ratings.

For 1.5-300HP drive ratings, 120VAC customer supplied power
required for separate DB contactor operation.

For 400-600HP drive ratings, DB uses drive contactor.

Enclosure Type

IP00 (Open).

Altitude Derating

1,000 meters (3,300 feet) maximum without derating.

Mounting Requirements

For 1397-DB-A001L-A150L and 1397-B003L-B300L kits, DB
contactor must be mounted in the vertical position.

For 1397-DB-B400L-B600L kits, DB uses drive contactor.

All other DB components may be mounted as required.

Installation

ATTENTION:

Electric Shock can cause injury or death.

Remove all power before working on this product.

The drive is at line voltage when connected to incoming AC
power. Before proceeding with any installation or
troubleshooting activity, disconnect, lockout and tag all
incoming power to the drive. Verify with a voltmeter than no
voltage exists at terminals L1, L2 and L3 on the drive input
power terminal block.

!

IMPORTANT

: The National Electrical Code (NEC) and local

regulations govern the installation and wiring of the dynamic brake.
AC power wiring, DC power wiring, control wiring and conduit must
be chosen and installed in accordance with these codes and the
information supplied in the 1397 User Manual.

All Open Chassis Dynamic Brake kits include a resistor assembly and
an open cage resistor enclosure. Each resistor assembly consists of a
backplate with one or more pairs of resistors mounted in a series or in
a series/parallel configuration.

Dynamic brake kits 1397-DB-A001L — A150L and
1397-DB-B003L — B300L include a DB contactor with (1) contactor
suppressor that mounts across the contactor coil.

Dynamic brake kits 1397-DB-B400L — B600L use the drive
contactor.

What These
Instructions Contain

Selection

ATTENTION:

Dynamic braking resistors may be

extremely hot. Install in an enclosure or provide adequate
clearance to ensure that nothing can come in direct contact
with, or in proximity to the DB resistors. Failure to observe
this precaution can result in severe burns and damage to, or
destruction of, the equipment.

!
