Rockwell Automation 1606-XLSRED40 Power Supply Reference Manual - Manual (Page 7)

All parameters are specified at 24V, 40A output current, 26°C ambient and after a 5 minutes run-in time, unless noted otherwise.
Rockwell Automation Publication 1606-RM010A-EN-P — February 2014 7
Bulletin 1606 Switched Mode Power Supplies
6. Terminals and Wiring
Input Output
Type Screw termination
IP20 Finger safe construction.
Suitable for field installation.
Screw termination
IP20 Finger safe construction.
Suitable for field installation.
Solid wire 0.5-6mm 2 0.5-16mm 2
Stranded wire 0.5-4mm 2 0.5-10mm 2
American Wire Gauge 20-10 AWG 22-8 AWG
Max. wire diameter 2.8mm (including ferrule) 5.2mm (including ferrule)
Wire stripping length 7mm / 0.275inch 12mm / 0.5inch
Screwdriver 3.5mm slotted or Pozidrive No 2 3.5mm slotted or Pozidrive No 2
Recommended tightening torque 0.8Nm, 7lb.in 1.2Nm, 10.6lb.in
To connect the chassis to ground, use a ring-type terminal (ring cable lug) which is suitable for a M4 screw and connect
it to the chassis ground terminal on top of the unit.
Instructions:
a) The external circuitry of all terminals must meet the safety requirements stipulated by IEC/EN/UL 60950-1: SELV.
b) Use appropriate copper cables that are designed for minimum operating temperatures of:
60°C for ambient up to 45°C and
75°C for ambient up to 60°C and
90°C for ambient up to 70°C minimum.
c) Follow national installation codes and installation regulations!
d) Ensure that all strands of a stranded wire enter the terminal connection!
e) Screws of unused terminal compartments should be securely tightened.
f) Ferrules
are allowed.
g) Do not connect or disconnect the wires from the terminals below -25°C (-13°F).
