(7)

10000021873

(Version 00)

Specification

Value

Dimensions

288.9 mm (height) x 139.7 mm (depth) x 44.5 mm (width)

11.37 in. (height) x 5.5 in. (depth) x 1.75 in. (width)

Approximate Shipping Weight

300g (0.66 lbs) (includes carton)

Storage Temperature

-40 to +85°C (-40 to +185°F)

Operating Temperature

0 to 55°C (32 to 131°F)

Operating Humidity

5 to 95% at 55°C (non-condensing)

Shock
Non-operating

Operating


50g

30g

Operating Vibration

2g @ 10-500Hz

Maximum Operating Voltage

150 VDC

Max. Module Operating Current

Per Point:
Per Module:


2 Amps (1492-CABLE connection pins are limited to 2A per pin)

12 Amps

Agency Certifications



UL Classified: Under UL File Number E113724

Fusing

Two, 4 Amps, 5 x 20 mm

CSA
CE: compliant for all applicable directives

Pollution Degree

2

Environmental Rating

IP20

VII. 1492-CM800-LD006 Conversion Module Specifications

(Operating specifications are when installed in the Conversion System base / cover-plate assembly)

Refer to the Wiring Diagram(s) for
current limits for a specific configuration.

NOTICE

BUL. 592 E1 PLUS O.L. RELAY
APPLICATION AND INSTALLATION
INSTRUCTION SHEET

10000015209 00

- - - - - - - - -

- - - - - - - - -

4

4

B

Conversion Module

Compatible 800

Output Module

Compatible 1756

Module

Required 1492 Cable

1492-CM800-LD006

B820-008

1756-OB8

1492-CABLEU

1492-CM800-LD006

B820-008

1756-OC8

1492-CABLEU

1492-CM800-LD006 Conversion Module

20-Pin Connector for 1492-CABLEU

Mating Connector for
B800 Terminal Block

De-energize and lockout any and all power to all I/O field devices connected to the Modicon 800 I/O
housing, and the power to the 800 I/O housing itself. Ensure all power is de-energized and locked out
to any device in the control cabinet where the conversion is to be performed. Ensure work is
performed by qualified personnel.

WARNING
