background image

(3)

IV. Conversion Module Specifications

(Operating specifications are when installed in the Conversion System base / cover-plate assembly)

III. Compatibility

1771

Analog I/O Module

1756

Analog I/O Module

1492

I/O Conversion Module

1492

Cable

1771-OFE1

1756-OF6VI

1492-CM1771-LA003

1492-CONACAB005E

1771-IG (Qty 2) (Digital)

1756-IG16

1492-CM1771-LA003

1492-C005005XS

1771-OG (Qty 2) (Digital)

1756-OG16

1492-CM1771-LA003

1492-C005005XS

1771-OFE2

1756-OF6CI

1492-CM1771-LA003

1492-CONACAB005E

Foot Notes:

To understand any issues concerning I/O module compatibility, refer to the Installation Manuals for the specific

1771 and 1756 I/O modules involved.

The 3 numbers indicate the length of the 1492 Cable. Recommended cable lengths of 0.5M are shown.

Additional cable lengths are as follows:
1.0M = 1492-CONACAB010E

The 6 numbers indicate the cable length of each portion of the 1492 Cable. Recommended cable lengths of

0.5M / 0.5M are shown. Additional cable lengths are as follows:

1.0M / 1.0M = 1492-C010010XS
0.5M / 1.0M = 1492-C005010XS
1.0M / 0.5M = 1492-C010005XS

Specification

Value

Dimensions

Approximate Shipping Weight

Storage Temperature

-40 to +85 C (-40 to 185 F)

Operating Temperature

0 to 60 C (32 to 40 F)

Operating Humidity

5 to 95% at 60 C (non-condensing)

Shock
Non-operating

Operating


50g
30g

Operating Vibration

2g at 10 to 500Hz (Agrees with 1756 I/O module specification)

Maximum Operating Voltage

30

Vdc

Max. Module Operating Current

Per Point:
Per Module:

Agency Certifications



UL Classified: Under UL File Number E113724

CSA

CE: compliant for all applicable directives

Pollution Degree

2

Environmental Rating

IP20

Refer to the Wiring Diagram(s) for
current limits for a specific configuration.

NOTICE

11.81 in. (height) x 4.38 in. (depth) x 1.5 in. (width)
300 mm. (height) x 111.25 mm (depth) x 38.1 mm (width)

250.6 g (0.55 lbs) (includes carton)

2 Amps
12 Amps

PN-114289
DIR 10000060100 (Version 01)
Publication 1492-IN047B-EN-E
