1329I Integrated Drive/Motor CE Filter Option Kit

Filter Installation

1. Mount the NEMA 12 Enclosed CE filter.

The cable length from the filter to the drive/motor must be less than 3
meters (10 feet).

2. The RFI filter must be connected between the incoming AC supply line

and the drive input terminals.

Important:

The filter may cause ground leakage currents. Therefore, a solid
ground connection must be provided as shown on the following
page.

ATTENTION:

To prevent electrical shock, disconnect the power

source before installing or servicing.

ATTENTION:

The National Codes and standards (NEC, VDE,

BSI, etc.) and local codes outline provisions for safely installing
electrical equipment. Installation must comply with specifications
regarding wire types, conductor sizes, branch circuit protection,
and disconnect devices. Failure to do so may result in personal
injury and/or equipment damage.

ATTENTION:

To guard against possible equipment damage, RFI

filters can only be used with AC supplies that are nominally
balanced with respect to ground. In some installations, three-
phase supplies are occasionally connected in a 3-wire
configuration with one phase grounded (Grounded Delta). The
filter must not be used in Grounded Delta supplies.
