Rockwell Automation Publication 1608M-UM001A-EN-P - September 2013 7
Chapter
2
Installation
System Components The MegaDySC system consists of two enclosures including one “DySC 400 A
Module” MegaDySC section and one Automatic Bypass Switchboard, which are
shipped separately and must be mechanically and electrically interconnected at
the time of installation. The MegaDySC section houses the static bypass and
voltage sag-correction electronics as well as the optional extended-run (ER)
module. The Automatic Bypass Switchboard houses the maintenance bypass
circuit breaker (CBB), the MegaDySC input (CBI) and output (CBO) circuit
breakers, automatic controls, and the i-Sense® voltage-monitoring sensor.
This document applies to the following MegaDySC System Models:
Table 1 - MegaDySC System Models
Catalog Number Current Rating Voltage
Rating
3 /
4-wire
SR / ER
1608M-400A380V3S 400A 380V 3 SR
1608M-400A380V3E 400A 380V 3 ER
1608M-400A380V4S 400A 380V 4 SR
1608M-400A380V4E 400A 380V 4 ER
1608M-400A400V3S 400A 400V 3 SR
1608M-400A400V3E 400A 400V 3 ER
1608M-400A400V4S 400A 400V 4 SR
1608M-400A400V4E 400A 400V 4 ER
1608M-400A415V3S 400A 415V 3 SR
1608M-400A415V3E 400A 415V 3 ER
1608M-400A415V4S 400A 415V 4 SR
1608M-400A415V4E 400A 415V 4 ER
1608M-400A460V3S 400A 460V 3 SR
1608M-400A460V3E 400A 460V 3 ER
1608M-400A460V4S 400A 460V 4 SR
1608M-400A460V4E 400A 460V 4 ER
1608M-400A480V3S 400A 480V 3 SR
1608M-400A480V3E 400A 480V 3 ER
1608M-400A480V4S 400A 480V 4 SR
1608M-400A480V4E 400A 480V 4 ER
