Back cover – Rockwell Automation 1394 Analog Servo System Firmware User Manual
Page 8
Publication 1394-6.1 — February 2000
74102-206-01(01)
Supersedes Publication 1394-6.1 January 1998
© 2000 Rockwell International. All Rights Reserved. Printed in USA.
If your 1394 system
module is:
Attach the firmware upgrade
label next to the data name plate,
as shown in:
5 and 10 kW
(Series A and B)
Figure 1
5 and 10 kW
(Series C)
Figure 2
22 kW
(any series)
Figure 3
