Installing New 1394 Analog Servo System Firmware !
Publication 1394-6.1 — February 2000
Note: To identify the series of your 1394 System Module look in
the SERIES field on the data name plate.
5.
6. Pull the input wiring board straight out (without twisting).
Important: Twisting the wiring board can damage the connector
on the back of the board.
If your 1394 system
module is: Then:
5 and 10 kW
(Series A and B systems) 1. Remove the upper and lower
control board screws (refer to
Figure 1).
2. Slide the input wiring board
and control board assembly to
the left until the connector on
the right side of the wiring
board disengages (refer to
Figure 1).
3. Remove the upper and lower
input wiring board screws.
4. Go to main step 6.
5 and 10 kW
(Series C systems) 1. Remove the upper, lower, and
side control board screws
(refer to Figure 2).
2. Unplug the ribbon cable from
the input wiring board.
3. Remove the upper and lower
input wiring board screws.
4. Go to main step 6.
22 kW
(any series) 1. Remove the front and side
control board screws (refer to
Figure 3).
2. Unplug the ribbon cable from
the input wiring board.
3. Remove the upper and lower
input wiring board screws.
4. Go to main step 6.
