Rockwell Automation 1394 Analog Servo System Firmware User Manual
Page 4
"
Installing New 1394 Analog Servo System Firmware
Publication 1394-6.1 February 2000
Figure 1
Removing the Input Wiring Board from 5 and 10 kW Systems (Series A and B)
Figure 2
Removing the Input Wiring Board from 5 and 10 kW Systems (Series C)
Upper Control
Board Screw
Align connectors and push here to
engage wiring board with control board
Push here to disengage
wiring board with control board
Firmware Upgrade Label
Opening for HIM Cable
Input Wiring Board Screws (2)
Lower Control
Board Screw
Data Name Plate
Firmware Upgrade Label
Opening for HIM Cable
Input Wiring Board Screws (2)
Side Control
Board Screw
Data Name Plate
Upper Control
Board Screw
Lower Control
Board Screw
Ribbon Cable
