Figure 6: 4-port devicebox tap wiring diagram – Rockwell Automation 1485 DeviceBox Tap User Manual
Page 3
3
Figure 5: 4-Port DeviceBox Tap
Part Number: 1485P–P4T5–T5
Dimensions—mm (inches)
209.29
(8.24)
48.0
(1.89)
98.04
(3.86)
ЙЙЙ
ЙЙЙ
ЙЙЙ
ЙЙЙ
ЙЙЙ
ЙЙЙ
ЙЙЙ
Й
67
(2.625)
197
(7.75)
44.4
(1.71)
1485P-P4T5-T5: PG16 cable grips (2 places)
1485P-P4T5-T5C: PG9 cable grips (2 places)
Figure 6: 4-Port DeviceBox Tap
Wiring Diagram
U10
Black
Blue
Drain
White
Red
Red
White
Drain
Blue
Black
Red
White
Drain
Blue
Black
Black
Blue
Drain
White
Red
Red
+24V
White Can H
Blue
Can L
Black Common
U8
U5
U3
Black
Blue
Drain
White
Red
Red
White
Drain
Blue
Black
U6
U1
Note: Trunk Connections: U1, U6
Drop Connections: U8, U3, U10, U5
