Rockwell Automation 1485 DeviceBox Tap - Manual (Page 2)

2
Figure 2: 8-Port DeviceBox Tap
Wiring Diagram
U10
Black
Blue
Drain White
Red
Red White Drain Blue Black
Red
White
Drain
Blue
Black
Black
Blue
Drain
White
Red
Red +24V
White Can H
Blue Can L
Black Common
U8
U5 U3
Black
Blue
Drain White
Red
Red White Drain Blue Black
U6 U1
U9
U4
Black
Blue
Drain White
Red
Red White Drain Blue Black
Black
Blue
Drain White
Red
Red White Drain Blue Black
U7
U2
Note: Trunk Connections: U1, U6
Drop Connections: U2, U4, U5, U7, U8, U9, U10
Figure 3: 2-Port DeviceBox Tap
Part Number: 1485P–P2T5–T5
Dimensions—mm (inches)
42.67
(1.68)
111.25
(4.38)
98.04
(3.86)
67
(2.625)
ЙЙЙЙЙЙЙ
ЙЙЙЙЙЙЙ
ЙЙЙЙЙЙЙ
ЙЙЙЙЙЙЙ
Й
Й
98
(3.875)
1485P-P2T5-T5: PG16 cable grips (2 places)
1485P-P2T5-T5C: PG9 cable grips (2 places)
44.4
(1.71)
Figure 4: 2-Port DeviceBox Tap
Wiring Diagram
U4
U2
U3 U1
Black Blue Drain White Red
Red White Drain Blue Black
Red
White
Drain
Blue
Black
Red +24V
White Can H
Blue Can L
Black Common
Note: Trunk Connections: U1, U3
Drop Connections: U2, U4
Black
Blue
Drain
White
Red
