• the protruding lip (see
below) on the inner surface of each seal,
which replaces the o-rings, is seated firmly in the o-ring groove (see
below).
Reconnecting the Motor
To reattach your existing series B IP67 cables or attach your new series B
IP67 cables to the connectors on the motor housing:
1. Push the input cable down onto the motor power connector until it is firmly
seated.
2. Push the output cable down onto the resolver or encoder connector until
it is firmly seated.
1
2
